Brand Name : SS
Certification : SGS
Place of Origin : CHINA
MOQ : 1m2
Price : US $3-5 / Square Meters
Payment Terms : L/C, T/T, Western Union
Supply Ability : 1000m2/week
Delivery Time : Shipped in 2 days after payment
Packaging Details : Plain Weave 40 60 80 100 150 200 Mesh N4 N6 Corrosion Resisting Pure Nickel Wire Mesh 1.Inside use carton pipe for support+wire mesh layer+water proof paper. 2.Outside use plastic wooden bags +wooden case/carton pipes/wooden pallets. 3.Also we can as per y
material : FeCrAl wire
grade : 100% pure
used : filter
wire dia : 0.010 to 1.20mm
width : 1m
length : 30m
feature : Acid resistance
roll size : 1m*30m/roll
iron chromium aluminum FeCrAl woven wire mesh screen/Cr20Ni80 FeCrAl woven wire mesh for electric cigarette atomizer
1.Material:Cr20Ni80, Cr15Ni60,Cr20Ni35, Cr20Ni30.
2.characteristics:
characteristic has bears the acid and alkali,against leakage ability strongly,the easy curl,the cost low status.Widely uses in the battery profession,the manufacture nickel cadmium,the nickel battery,the carp iron electron battery.
Alloy | Temperature |
Cr21Al4 | 1100oC |
Cr21Al6 | 1250oC |
Cr23Al5 | 1250oC |
Cr25Al5 | 1250oC |
Kanthal D | 1200oC |
Kanthal A-1 | 1350oC |
poperties of FeCrAl Mesh:
specification:
Mesh/Inch | Wire Gauge SWG | Aperture mm |
3 | 14 | 6.27 |
4 | 16 | 4.27 |
5 | 18 | 3.86 |
6 | 18 | 3.86 |
8 | 20 | 2.26 |
10 | 20 | 1.63 |
20 | 30 | 0.95 |
30 | 34 | 0.61 |
40 | 36 | 0.44 |
50 | 38 | 0.36 |
60 | 40 | 0.30 |
80 | 42 | 0.21 |
100 | 44 | 0.172 |
120 | 44 | 0.13 |
150 | 46 | 0.108 |
160 | 46 | 0.097 |
180 | 47 | 0.09 |
200 | 47 | 0.077 |
Applications of FeCrAl Heating Mesh:
FeCrAl Mesh is primarily utilized as drying and heating devices in metallurgy, colliery, dying, food storage, hospital, high density factory, industrial electric furnace, household appliances, gas burners and infrared equipments and heaters.
For your diverse application requirements, our heating mesh in various sizes provide excellent performance to become your preferred product. Contact us to discover how we have become the pioneer industrial mesh vendor since 1984.
Item | FeCrAl wire mesh |
Components | Fe Cr Al |
Material | 1Cr13Al4, 0Cr25Al5, 1Cr12Al4.... |
Weave type | Plain/twill weave |
Mesh count | 2-200 mesh |
Width | 0.2m-2m ,can be customized |
Length | 1-30m/roll , can be customized |
Max-working temperature: | 1Cr13Al4 - 950° 1Cr21Al4 - 1100° |
Features | Heat resistance , Oxidation resistance. |
Applications | Mainly used as the drying and heating equipment in metallurgy , dyeing, food factory ,and so on. |
Stock and customized | All are available |
Sample | Free |
Our Services
![]() |
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer Images |
